Push Back Racking

Push Back Racking

Urgo Push Back Racking combines high-density storage with high-speed access by conventional forklift trucks, ideal for businesses that need to store large batches of the same SKU. Urgo Push Back Rack systems are available in structural or roll-formed fram

Description

Urgo Push Back Racking combines high-density storage with high-speed access by conventional forklift trucks, ideal for businesses that need to store large batches of the same SKU. Urgo Push Back Rack systems are available in structural or roll-formed frames. Urgo Push Back Rack systems work by placing pallet loads on a series of nesting carts fed forward by gravity on rigid structural steel rails.
Urgo Push Back Racking carts nest together with a low profile to help save vertical space.As a pallet is loaded from the front, it pushes the pallet behind it back one position. The front pallet is removed when unloading and the rear pallets automatically come forward to the front picking position. This allows for easily accessible Last-In-First-Out (LIFO) inventory management. Operators can store product from 2-5 pallets deep, with front-only loading from a single aisle.
This kind of rack offers more versatile storage than Drive-In rack because each lane flows independently and vertical storage operates separately from lanes below. Multiple pick facings for a variety of SKUs can be stored and retrieved without disturbing other product above or below in a single-lane or double-lane format.
Features:
1. Pick face remains constantly full
2. A low damage environment, with truck outside racking always
3. High storage density with speedy accessibility, but FILO
4. Conventional handling equipment can be used
5. Pallet quality may not be so critical as carts or cradles are always used

Please consult the service hotline for more details:  +86-25-52127166
